Fully automatic single-head servo filling machine

Machine Type: Fully Automatic Single Head Servo Filling Machine
Model: YL-G01Z
Filling Range: 5 ml – unlimited
Filling Speed: 1500–2000 bottles/hour
Filling Accuracy: ±0.5–1%
Applicable Bottle Height: 30–200 mm
Applicable Bottle Mouth: 15–40 mm
Hopper Volume: 100 L
Power Supply: AC 220V / 50Hz / 1.5 kW
Machine Weight: 150 kg
Application:
Automatic filling of small- to medium-size bottles for liquids like daily chemicals, cosmetics, or sauces.

Content

Features

1.Servo-driven quantitative filling with high accuracy (±0.5–1%)

2.Fully automatic operation: bottle feeding, positioning, filling, cap placing, and capping

3.PLC touch screen control, simple operation and stable performance

4.Anti-drip filling system, no leakage and no stringing

5.Bottle mouth positioning and pressing device, suitable for small-neck bottles

6.Compact structure, fast filling speed, and high cost performance


Applications

1.Suitable for liquid and semi-liquid products

2.Widely used in food, pharmaceutical, cosmetic, chemical, and daily chemical industries

3.Ideal for filling products such as detergents, shampoos, lotions, oils, sauces, and liquid chemicals

4.Compatible with various bottle types and sizes


Video
Parameter
Filling range 5ML - Unlimited
Filling accuracy 0.5-1%
Filling speed 1500-2000 bottles/hour
Applicable bottle height 30-200mm
Applicable bottle mouth 15-40mm
Hopper volume 100L
Voltage power 220V/50HZ/1.5KW
Machine weight 150kg
Machine size 1800*850*1400mm
Details
